I. Basic Parameters
Model: Secura®
Type of Balance: Analytical Balance
Power Requirements: Line voltage 100–240 V, 50–60 Hz
II. Functional Features
Core Functions: Supports the Sqmin function. The division values are 0.01 | 0.1 mg, and the typical stabilization times are 6 | 2 s. It has a three-level safety time setting, password protection, a color touchscreen, fully automatic internal calibration (isoCAL), sample identification, and tamper protection (password protection).
Interaction and Safety: It has multilingual support (such as English, Chinese, etc.), real-time level confirmation. The repeatability is 0.03 | 0.07 mg, and it is equipped with a Kensington anti-theft lock.
Body Protection: The outer shell can be cleaned with acetone, and the glass components of the wind shield are coated to reduce static electricity.
III. Compliance Information
Certifications: Complies with GLP and GMP regulations. It supports GLP/GMP print output and has passed the legal verification in China.
IV. Dimension Specifications
Dimensions: 218 × 376 × 316 mm. The pan diameter is ⌀ 80 mm, and the height of the weighing chamber is 218 mm.
V. Application Scenarios
Industrial Fields: Medicine, laboratories, academic research, pharmaceuticals, chemistry, automotive automation, etc.
Laboratory Applications: Standard weighing, density determination, weight checking, animal weighing; Special applications include formulation, component analysis, and statistical conversion.
VI. Operation and Connection
Operation: The maximum sample weights are 120 | 220 g, and it supports calibration history records.
Data Interfaces: Mini USB. It supports direct connection to a PC and Sartorius printers. The data can be transmitted to Windows programs, and programmable interval output is supported.
VII. General Parameters
Weighing Units: Includes multiple units such as g, kg, lb, etc.
Performance: The linearity is 0.1 | 0.2 mg. It has chemical resistance (Yes), and complies with the minimum sample size of 8.2 mg according to USP/PhEur. The dust cover comes with an operation manual.
