I. Basic Information
Product Line: Entris® II Essential Line
Packaging Dimensions: 350 × 445 × 250 mm
Model: Entris® II
Type of Balance: Precision Balance
II. Power Parameters
Transformer Output: 15 VDC, ±5%, 0.53 A
Power Requirements: 100–240 VAC, ±10%, 50–60 Hz, 0.2 A
III. Functional Features
Bottom Weighing: Supported; Typical Stabilization Time: ≤ 0.9 s; Division Value: 10 mg
Display: ED Screen with Touch Technology; Calibration Method: Fully Automatic Internal Calibration (isoCAL)
Language Support: English, German, French, Italian, Spanish, Portuguese, Russian, Polish
Level Adjustment: Manual Level Adjustment; Repeatability: 10 mg
Anti-theft Lock Device: Kensington Lock, which can be connected to an anti-theft chain
IV. Compliance and Certifications
Metrological Certification: Legal Verification (China)
V. Dimension Specifications
Dimensions (W × D × H): 219 × 317 × 94 mm; Pan Diameter: 182 × 182 mm; Height of Weighing Chamber: None
VI. Application Scenarios
Application Programs: Animal Weighing, Calculation | Free Factor, Counting, Density Determination, Percentage Weighing, Component | Total, Weighing, Quantitative Dispensing, Mixture | Net Total, Statistics, Peak Hold, Weight Checking, Mass Unit Conversion, Under-the-Pan Weighing
VII. Operating Conditions
Operating Temperature: +10 – +30 ℃; Maximum Sample Weight: 620 g
VIII. Data Interfaces
Data Interfaces: RS232, USB C
IX. General Parameters
External Calibration Weight: 500 g | F2; Sensitivity Drift: ±2.0 ppm/K (between +10℃ and + 30℃)
Weighing Units: gram, kilogram, carat, pound, ounce, troy ounce, Hong Kong tael, Singapore tael, Taiwan tael, grain, pennyweight, milligram, parts per pound, Chinese tael, momme, Austrian carat, tola, baht, misgar, newton
Linearity: 20 mg; Dust Cover: None
