The S-type load cell, as the name indicates, can be easily identifed by S-shaped body. They can be loaded either in tension or compression, and used for single ormultiple-cell application if the output is rationalized.
STC is made of Aluminum, Alloy Steel or Stainless Steel, sealed to IP67 providing excellent protection against moisture and humidity.
FEATURES
• Capacities
Aluminum construction—5, 10, 20 kg;
Alloy Steel construction— 25 to 5000 kg, 250 to 40k lbs
• Bi-direction (tension/compression)
• Rationalized output
• NTEP Class III 5000S, lllL10000 approval from 250 lbs to 20k lbs
OPTIONAL FEATURE
• Stainless steel available
• FM approval available
APPLICATIONS
• Electro-mechanical conversion scales
• Silo/hopper/tank weighing
• Crane scales
• Fork-lift scales
• Dosing/flling
• Universal material tester
• Tensile/pulling force measurement
